Commercial Doors
American Tradition™
9000 Series
  • 9200 Models - 2 5/8"”-Thick Environmentally Compliant Polyurethane (2" Base & 5/8" Overlay)
    and 0.081 Tested U-Factor
  • 9600 Models - 2”-Thick Environmentally Compliant Polyurethane (1-3/8" Base & 5/8" Overlay) and
    0.096 Tested U-Factor
  • 42 Models Available with Multiple Style Options
  • 26-Gauge Galvanized Steel
  • Polyurethane Overlay Boards
  • 17 Base & Overlay Colors
  • 10 Window Options
  • Full Thermal Break
  • Available with Wind Load
  • Lifetime Rust & Delamination
  • 10 Year Finish
Commercial Aluminum
  •  1 3/4"-Thick
  • Rust and Corrosion Free
  • Commercial-grade Aluminum
  • CA-320 Heavy-duty Frame with Insulated Rail Option
  • CA-315 Larger Glass Area with Heavy-duty Outer
  • CA-110 Narrow Line Frame
  • Tongue & Groove Joints on CA-320 & CA-315 have Bulb Seal that meets IECC Air Infiltration requirements
  • Solid Panels available
  • Wide Variety of Glass Options
  • 11 Powder Coated Wood Grain Colors
  • 10 Painted, 3 Anodized and Custom Colors
  • 1 Year Warranty
Insulated Aluminum
5000 Series
  •  3”, 2", 1 3/4" -Thick Environmentally Compliant Polyurethane
  •  5800 Models - 0.089 Tested U-Factor
  •  5200 Models - 0.110 Tested U-Factor
  •  5700 Models - 0.097 Tested U-Factor
  •  24-Gauge Aluminum with Full Thermal Break
  •  Air Infiltration Seal (5800 & 5200)
  •  Available with Wind Load
  •  10 Year Warranty
  •  10 Year Finish
Insulated Steel 800 Series
  •  3”-Thick Environmentally Compliant Polyurethane
  •  0.089 Tested U-Factor
  •  26-Gauge Galvanized Steel
  •  Air Infiltration Seal & Full Thermal Break
  •  Available with Wind Load
  •  19 Color Options
  •  10 Year Warranty
  •  10 Year Finish
Insulated Steel 2000 Series
  • 2”-Thick Environmentally Compliant Polyurethane
  • 0.094 Tested U-Factor
  • 26-Gauge Galvanized Steel
  • Air Infiltration Seal & Full Thermal Break
  • Available with Wind Load
  • 24 Color Options
  • 10 Year Warranty
  • 10 Year Finish, 12 Year for Plank Options
Insulated Steel 700 Series
  •  1 3/4”-Thick Environmentally Compliant Polyurethane
  •  0.093 Tested U-Factor
  •  26-Gauge Galvanized Steel
  •  Full Thermal Break
  •  Available with Wind Load
  •  24 Color Options
  •  10 Year Warranty
  •  10 Year Finish, 12 Year for Plank Options
Insulated Steel 600 Series
  • 1-3/8”-Thick Environmentally Compliant Polyurethane
  • 0.106 Tested U-Factor
  • 26-Gauge Galvanized Steel
  • Full Thermal Break
  • Available with Wind Load
  • 24 Color Options
  • 10 Year Warranty
  • 10 Year Finish, 12 Year for Plank Options
Ribbed Steel Series
  • 2” Thick
  • 20-, 24- or 25-Gauge Steel Options
  • Non-insulated, Insulated Laminate Back
    or Insulated Steel Back Options
  • Non-Insulated
  • Tongue-and-Groove Construction
  • Not included in DASMA TRV Program
  • Available with Wind Load
  • 9 Color Options
  • 4 Panel Options
  • 1 Year Warranty
Residential Doors
American Tradition™ Series
  • 9200 Models - 2 5/8"”-Thick Environmentally Compliant Polyurethane (2" Base & 5/8" Overlay)
    and 0.081 Tested U-Factor
  • 9600 Models - 2”-Thick Environmentally Compliant Polyurethane (1-3/8" Base & 5/8" Overlay) and
    0.096 Tested U-Factor
  • 42 Models Available with Multiple Style Options
  • 26-Gauge Galvanized Steel
  • Polyurethane Overlay Boards
  • 17 Base & Overlay Colors
  • 10 Window Options
  • Full Thermal Break
  • Available with Wind Load
  • Lifetime Rust & Delamination
  • 10 Year Finish
Aluminum 5000 Series
  • 2”-Thick Environmentally Compliant Polyurethane
  • 0.110 Tested U-Factor (5200 Models);
    0.097 Tested U-Factor (5700 Models)
  • Corrosion-Resistant Aluminum
  • Air Infiltration Joint Seal
  • Full Thermal Break
  • Available with Wind Load
  • 4 Panel Options
  • 36 Window Options
  • Stucco Embossed
  • Lifetime Delamination Warranty
Aluminum Full-View
RA360 Series
  • Rust and Corrosion Free
  • Commercial-grade Aluminum
  • Tongue & Groove Joints have Bulb Seal that meets IECC Air Infiltration requirements
  • Optional Insulated Rail
  • 11 Powder Coated Wood Grain Color Options
  • 10 Painted Finish Options
  • 3 Anodized Color Options
  • Custom-matched Color & Powder Coating available
  • 5 Year Warranty
Insulated Steel 2000 Series
  • 2”-Thick Environmentally Compliant Polyurethane
  • 0.094 Tested U-Factor
  • Air Infiltration Joint Seal
  • Full Thermal Break
  • 26 Gauge Galvanized Steel
  • Available with Wind Load
  • 24 Color Options
  • 9 Panel Options
  • 15 Residential Models
  • 36 Window Options
  • Lifetime Rust & Delamination
  • 10 Year Finish, 12 Year for Plank Options
Insulated Steel 700 Series
  • 1-3∕4”-Thick Environmentally Compliant Polyurethane
  • 0.093 Tested U-Factor
  • Full Thermal Break
  • 26-Gauge Galvanized Steel
  • Available with Wind Load
  • 24 Color Options
  • 9 Panel Options
  • 15 Residential Models
  • 36 Window Options
  • Lifetime Rust & Delamination
  • 10 Year Finish, 12 Year for Plank Options
Insulated Steel 600 Series
  • 1-3∕8”-Thick Environmentally Compliant Polyurethane
  • 0.106 Tested U-Factor
  • 26-Gauge Galvanized Steel
  • Full Thermal Break
  • Available with Wind Load
  • 24 Color Options
  • 9 Panel Options
  • 15 Residential Models
  • 36 Window Options
  • Lifetime Rust & Delamination
  • 10 Year Finish, 12 Year for Plank Options
Steel 2400 Series
  • 2” Thick
  • 24-Gauge Galvanized Steel
  • Tongue-and-Groove Construction
  • 0.215 Tested U-Factor available
  • Available with Wind Load
  • 9 Color Options
  • 5 Panel Options
  • 18 Residential Models
  • 34 Window Options
  • Lifetime Rust-Through
Steel 2500 Series
  • 2” Thick
  • 25-Gauge Galvanized Steel
  • Tongue-and-Groove Construction
  • 0.231 Tested U-Factor available
  • Available with Wind Load
  • 6 Color Options
  • 4 Panel Options
  • 16 Residential Models
  • 33 Window Options
  • Lifetime Rust-Through
